Part 2 of our Lexus IS300 3UZ swap is officially underway. This is where the build takes a major step forward. The factory 2JZ-GE comes out, the engine bay becomes a blank canvas, and we pick up the 3UZ-FE V8 that will completely transform this car.
This swap is about more than just horsepower. It's about torque, sound, driving feel, and building something different within the Toyota and Lexus world.
We're replacing the factory 3.0-liter 2JZ-GE inline-six with a Toyota 4.3-liter 3UZ-FE V8 to create a naturally aspirated, V8-powered Lexus IS300 drift car.
If you missed the teardown process, check out Part 1 of our Lexus IS300 3UZ swap build series, where we started removing the radiator support and wiring harness.
Planning your own swap? Browse our Lexus IS300 engine swap parts and Lexus IS300 performance parts at Lunatics Co.
Removing the Factory 2JZ-GE From the Lexus IS300
The factory 2JZ-GE is officially out.
In Part 1, we removed the wiring harness from the engine. Looking back, there are multiple ways to approach this.
Instead of disconnecting every single plug from the engine, it could have been easier to disconnect the ECU, fold the harness aside, and pull the engine with the harness still attached.
Either method works depending on the build.
Since this engine is coming apart and the harness will not be reused, separating everything made sense for our IS300.
Disconnecting the 2JZ Engine Harness and Supporting Systems
With the harness fully separated, the next steps included:
- Removing the ECU box and unplugging the remaining electrical connections
- Disconnecting coolant hoses and AC lines
- Disconnecting and removing power steering lines
- Disconnecting the fuel supply using the 17 mm fitting
- Removing multiple chassis grounds, including 14 mm ground points
- Draining the remaining coolant and fluids
There were a few moments of coolant spilling everywhere and fighting stuck clips, but eventually everything was disconnected.
At that point, the engine was officially free from the chassis.
We covered the full harness removal process in Part 1 of the 3UZ swap build.
Using an Engine Hoist to Remove the 2JZ-GE
Removing the factory 2JZ was also a learning experience.
We set up a new engine hoist along with an engine leveler to control the engine angle during removal.
The leveler was bolted to the factory engine lift points, allowing us to adjust the angle while lifting the engine out of the chassis.
For someone who has only pulled a motor once before, this was a hands-on learning moment.
Hook placement, chain length, engine balance, and clearance all matter.
Once tension was applied and the engine mounts were cleared, the 2JZ slowly came out of the engine bay.
Just like that, the IS300 no longer had its inline-six.
Pulling the 2JZ marked a huge milestone in the 3UZ swap process. The chassis was now officially ready for V8 fitment.
Picking Up the Toyota 3UZ-FE 4.3L V8
The next day, we picked up the Toyota 3UZ-FE V8.
The engine came from a vehicle involved in a front-end collision.
It had been sitting for a while, which explained some of the surface rust on the external components. However, the engine showed encouraging signs of previous maintenance.
We also reviewed the vehicle's Carfax report, which showed consistent maintenance history before the accident.
For a swap like this, maintenance is critical before installation.
Since the engine is already out of the vehicle, it makes sense to replace components that would be much harder to access once the engine is installed.
What Maintenance Should You Do Before a 3UZ Swap?
Before installing our used 3UZ-FE into the Lexus IS300, we're planning to refresh several important maintenance components.
Our preventative maintenance checklist includes:
- Timing belt replacement
- Water pump replacement
- Valve cover gasket replacement
- Front main seal replacement
- Rear main seal replacement
- Starter replacement
- Accessory pulley inspection and replacement
Completing this work while the engine is outside the car should make the swap easier and reduce the chances of having to repeat major disassembly later.
After the mechanical maintenance is completed, the engine will also be cleaned and refreshed cosmetically before test fitting.
We cover the full maintenance process in Part 3 of our Lexus IS300 3UZ swap series, including the timing belt, water pump, starter, seals, and valve cover gaskets.
Major Challenges of Swapping a 3UZ Into a Lexus IS300
A 3UZ swap is not a plug-and-play conversion.
There are several systems that need to be addressed before the 4.3-liter V8 can run properly in the IS300 chassis.
Some of the biggest challenges include wiring integration, fuel system compatibility, power steering, exhaust fabrication, and electronic throttle control.
1. Wiring the 3UZ-FE Into the Lexus IS300
Wiring is one of the biggest decisions in this project.
We need to determine how to integrate the 3UZ engine harness and ECU with the existing IS300 chassis wiring.
Options include modifying the harness ourselves or sending it to a specialist for a standalone or modified harness solution.
If the wiring isn't completed correctly, drivability and reliability can suffer.
That's why we're taking the time to plan the wiring before moving forward with the engine installation.
2. Adapting the Lexus IS300 Fuel System for the 3UZ
The 3UZ fuel feed configuration differs from the factory IS300 setup.
The fuel feed location and fittings are different, which means custom adaptation will be required.
We need to ensure the factory chassis fuel line can properly connect to the 3UZ fuel rail while maintaining safe fuel delivery.
For builds requiring additional fuel pump support, Lunatics Co carries the Xcessive Manufacturing IS300 Fuel Pump Mod.
All fuel system modifications must use components compatible with the fuel type and operating pressure, and all connections must be checked for leaks before startup.
3. Converting the IS300 Power Steering System
On the 3UZ, the hydraulic power steering pump is mounted on the opposite side compared with the factory 2JZ configuration.
This creates additional routing challenges when fitting the engine into the IS300.
One possible solution we're considering is converting to electric power steering.
An electric system could help free up room in the engine bay and eliminate some of the factory hydraulic plumbing.
Because this is being built as a drift car, steering feel, reliability, and clearance are all important considerations.
4. Custom Exhaust Fabrication for the 3UZ-FE
The exhaust will likely require custom fabrication to fit properly inside the IS300 chassis.
The biggest considerations are clearance around the steering components, engine mounts, transmission, and surrounding sheet metal.
Depending on the final engine position, the factory 3UZ exhaust manifolds may require modification or replacement.
This is one of the areas we'll address as we begin test fitting the engine.
5. Converting the IS300 to Drive-by-Wire Throttle
Our 3UZ-FE uses electronic throttle control, so we need to adapt the IS300 to work with an electronic accelerator pedal.
We're considering pedal assemblies from Lexus models such as the IS250, IS350, and GS430, depending on electrical compatibility and mounting requirements.
Proper pedal integration is important because the accelerator pedal signals must work correctly with the ECU and electronic throttle system.
The final setup must also maintain the necessary throttle safety functions and calibration.
Preparing the Lexus IS300 Subframe for the 3UZ
While the engine is out, this is the perfect time to address chassis modifications.
We're planning to remove and modify the front subframe to create the clearance needed for the 3UZ.
The subframe will also be prepared for an offset steering rack spacer from Para Max.
This setup is intended to improve steering clearance and help address binding at high steering angles.
Because this car is being built for drifting, steering angle and front suspension geometry are important parts of the overall build.
Any subframe modification must preserve structural integrity, and the finished steering system must be checked for interference, binding, and safe operation throughout its travel.
Suspension Upgrades Planned for the 3UZ IS300 Drift Car
In addition to the engine swap, we're planning several suspension upgrades to improve the car's handling and drifting performance.
Our planned upgrades include:
- Thicker front sway bar
- Higher spring-rate coilovers
- Replacement lower control arm bushings
- Replacement caster arm
- Rear upper control arms
Handling is just as important as power, especially for a drift car.
With the additional torque from the 3UZ V8, we want the suspension and steering systems to work together rather than simply focusing on engine performance.
For compatible chassis upgrades, browse our Lexus IS300 suspension and performance parts.
Additional Modifications We're Considering
Since the IS300 is already apart, we're also considering a few additional changes.
- Battery relocation
- ABS removal
- Manual brake booster conversion
- Hydraulic power steering removal
Some of these modifications may happen depending on budget, available time, and the final drivetrain configuration.
For now, the priority is completing the engine swap correctly and addressing the supporting systems needed to get the car running.
Changes to the braking and steering systems require careful engineering and testing because they directly affect vehicle safety.
What Parts Do You Need for a Lexus IS300 3UZ Swap?
Swapping a Toyota 3UZ-FE into a Lexus IS300 requires more than just the engine.
Depending on the transmission and engine management setup, you may need engine mount brackets, transmission adapters, clutch components, fuel system modifications, wiring solutions, and custom drivetrain parts.
Some useful components and collections available through Lunatics Co include:
- Lexus IS300 Engine Swap Parts
- Xcessive Manufacturing 1UZ/3UZ IS300 Engine Mount Brackets
- Xcessive Manufacturing IS300 UZ Engine Mounts
- Xcessive 1UZ/3UZ to TL70 Transmission Adapter Kit
- Xcessive Manufacturing IS300 Swap Driveshaft
- Xcessive Manufacturing Parts
- Complete Lexus IS300 Parts Catalog
Always verify compatibility with your specific engine, transmission, and chassis configuration before ordering.
Lexus IS300 3UZ Swap FAQ
Can you swap a 3UZ-FE into a Lexus IS300?
Yes. The Toyota 3UZ-FE 4.3-liter V8 can be installed in a first-generation Lexus IS300 with the appropriate engine mounts, transmission solution, wiring, fuel system, and supporting modifications.
What engine comes in the Lexus IS300 from the factory?
The 2001–2005 U.S.-market Lexus IS300 came equipped with the 3.0-liter Toyota 2JZ-GE inline-six engine.
What vehicles came with the 3UZ-FE V8?
The 3UZ-FE was used in several Lexus vehicles, including the LS430, GS430, and SC430. Exact applications and model years vary by market.
How much displacement does the 3UZ-FE have?
The Toyota 3UZ-FE is a naturally aspirated 4.3-liter V8 engine.
Is a 3UZ swap plug-and-play in an IS300?
No. A 3UZ swap requires modifications to engine mounting, transmission compatibility, wiring, fuel delivery, throttle control, exhaust routing, and other supporting systems.
What engine mounts work for a 3UZ IS300 swap?
Xcessive Manufacturing offers 1UZ/3UZ Engine Mount Brackets for the 2001–2005 Lexus IS300, designed to help position Toyota UZ-series V8 engines in the chassis.
Can you use a manual transmission with a 3UZ-FE?
Yes. A 3UZ-FE can be adapted to various manual transmissions using compatible adapter systems, flywheels, clutches, and supporting components.
For our build, we later selected a TL70 6-speed manual transmission from the Toyota 86, Scion FR-S, and Subaru BRZ platform. See Part 5 of our 3UZ swap series for the installation.
Should you replace the timing belt before installing a used 3UZ?
If the service history is unknown or the belt shows signs of age or wear, replacing the timing belt before installing the engine is a sensible preventative maintenance step.
We cover the timing belt, water pump, starter, and other maintenance work in Part 3 of our Lexus IS300 3UZ swap.
Where can I buy Lexus IS300 engine swap parts?
Lunatics Co carries a dedicated Lexus IS300 Swap Parts collection featuring engine, transmission, and drivetrain components for modified IS300 builds.
Our Lexus IS300 3UZ Swap Build Information
- Chassis: Lexus IS300
- Original engine: Toyota 2JZ-GE 3.0L inline-six
- Replacement engine: Toyota 3UZ-FE 4.3L V8
- Build purpose: Drift car
- Current stage: Factory engine removal and 3UZ acquisition
What's Next for Our Lexus IS300 3UZ Swap?
The 2JZ is out, and the 3UZ is home.
Next, we're moving into engine maintenance, followed by test fitting and mount positioning.
This is where the swap moves from teardown into fabrication and integration.
There's still a long road ahead, but progress is real.
In Part 3 of our Lexus IS300 3UZ swap series, we service the 3UZ-FE before installing it into the chassis.
That includes replacing the timing belt, water pump, starter, front main seal, valve cover gaskets, and other maintenance components.
If you're into Lexus IS300 builds, Toyota V8 swaps, 3UZ conversions, or custom engine projects, follow along as we move toward mounting, wiring, and firing up this V8-powered IS300.
The inline-six chapter is closed. The V8 era is officially beginning.
